SY 2.5mm 4 Core Cable-100m

SY 2.5mm 4 Core Cable

Available in 10, 20, 30 and 100m lengths

pplication:
Used as connecting cable, as measuring, checking and control cable in machine tool manufacturing, plant engineering and on assembly lines and production lines to meet stringent safety requirements. Suitable for fixed installations or flexible applications with unrestricted mobility without forced movement control and without exposure to tensile load. Installation permitted in dry and moist rooms. Outdoor installation not permitted.

• Standards: Generally BS6500 VDE0250
• Conductor: Class 5 annealed copper conductors to BS6360 / VDE0295
• Insulation:  PVC (Type TI2 to BS7655)
• Bedding: PVC (Type TM2 to BS7655
• Braiding: Galvanised Steel Wire Braid (GSWB)
• Sheath: PVC (Type TM2 to BS7655)
• Colour:  Transparent
• Voltage Rating: 300/500V
• Temperature rating: Flexing -15 to +70 C, Static -35 to +70 C
• Minimum bending radius: 6 x overall diameter

Core identification: Black with White numbers. (3 core and above to include Green/Yellow)
Coloured cores available on request
