T745

Air Conditioning Copper Tube Refrigeration Grade Pipe 15.88mm 5/8 30m

Premium 5/8" copper coiled tube from Lawton Tubes, designed for refrigeration and air conditioning systems. This 30-meter coil is made from high-quality phosphorus de-oxidised copper (Cu-DHP, CW024A), ensuring durability and corrosion resistance. Nitrogen-purged and capped for cleanliness, it meets EN 12735-1 standards, ideal for seamless installations. Perfect for HVAC professionals seeking reliable, flexible tubing with a 25-year warranty.
Ex. VAT
£191.97
Inc. Tax
£230.36

Description

Lawton Tubes 5/8" Copper Coiled Tube - 30m Coil

The Lawton Tubes 5/8" Copper Coiled Tube (30m) is a premium-grade copper tubing solution designed specifically for refrigeration and air conditioning applications. Manufactured to meet the rigorous standards of BS EN 12735-1, this 30-meter coil is ideal for HVAC professionals seeking reliable, durable, and easy-to-install tubing for a variety of systems. With its nitrogen-purged and capped design, this product ensures cleanliness and performance, backed by a 25-year warranty from Lawton Tubes.

Key Features

  • Premium Material: Crafted from phosphorus de-oxidised copper (Cu-DHP, CW024A) with a minimum copper content of 99.90% (including silver) and phosphorus content of 0.015-0.040%, ensuring excellent thermal conductivity and corrosion resistance.
  • 30-Meter Coil: Offers ample length for large-scale installations, minimising joints and enhancing system efficiency.
  • EN 12735-1 Compliance: Meets European standards for seamless copper tubes used in refrigeration and air conditioning, guaranteeing safety and reliability.
  • Clean and Protected: Nitrogen-purged and capped to maintain internal cleanliness, preventing contamination during storage and transport.
  • Mechanical Strength: Supplied in R220 (soft) temper with a minimum tensile strength of 220 N/mm², 40% elongation, and indicative hardness of 40-70 HVS VPN, ideal for flexible installations.
  • Working Pressure: Maximum working pressure (MWP) of 67 bar in annealed condition at 100°C (0.040" wall thickness, 19 SWG) or 79 bar in supplied condition, with a maximum test pressure of 1.5x MWP.
  • 25-Year Warranty: Lawton Tubes’ commitment to quality ensures long-term performance and peace of mind.

Applications

This 5/8" copper coiled tube is versatile and suitable for a wide range of applications, including:

  • Air conditioning systems (split and multi-split units)
  • Commercial and industrial refrigeration systems
  • Heat pump installations
  • Medical gas systems (where applicable)

Installation Guidelines

For optimal performance, follow Lawton Tubes’ recommended installation process for copper tubing and solder-type fittings:

  1. Cut the tube square using a tube cutter or fine hacksaw (32-tooth blade recommended) and remove burrs with a file or scraper.
  2. Clean the outside of the tube end thoroughly with sandpaper or sand cloth to the depth of the fitting, ensuring no dark spots remain.
  3. Clean the inside of the fitting to the tube stop using a wire brush, sandpaper, or sand cloth.
  4. Apply heat uniformly around the fitting with a torch. The correct brazing temperature has been reached when the brazing rod melts upon contact. Remove the flame and feed the brazing rod slightly off-centre at the bottom of the joint, proceeding across the bottom and up to the top, then returning to complete the joint. Wipe off excess brazing alloy with a cloth.

Why Choose Lawton Tubes?

Lawton Tubes, a leading UK manufacturer, is renowned for its high-quality copper tubing solutions. The 5/8" 30m copper coil is produced with strict adherence to quality control standards, ensuring durability, minimal maintenance, and maximum efficiency. Its flexible, coiled design simplifies installation in complex or confined spaces, making it a preferred choice for contractors and installers.

Technical Specifications

Specification Details
Outer Diameter 5/8" (15.88 mm)
Length 30 meters
Wall Thickness 0.040" (1.02 mm, 19 SWG)
Material Cu-DHP (CW024A) Copper
Minimum Copper Content 99.90% (including silver)
Phosphorus Content 0.015-0.040%
Temper R220 (soft)
Tensile Strength 220 N/mm² (minimum)
Elongation 40% (minimum)
Hardness (Indicative) 40-70 HVS VPN
Maximum Working Pressure 67 bar (annealed) / 79 bar (supplied) at 100°C
Standard EN 12735-1
Finish Nitrogen-purged, capped

Order Today

Elevate your HVAC and refrigeration projects with the Lawton Tubes 5/8" Copper Coiled Tube. Available now at AirconSpares.com, this 30m coil combines quality, reliability, and ease of installation for professional-grade results. Order today and trust in Lawton Tubes’ legacy of excellence!

More Information

Product NameAir Conditioning Copper Tube Refrigeration Grade Pipe 15.88mm 5/8 30m
SKUT745
mpn1826
c2c BrandLawton
