Armoured Cable 4 core 2.5mm SWA per metre

Armoured Cable 4 core 2.5mm SWA cable

Application: SWA Cable - power and auxiliary control cables for use in power networks, underground, outdoor and indoor applications and for use in cable ducting.

• Standards: BS5467, IEC 60502
• Conductor: Class 2 stranded plain copper conductor to BS EN 60228:2005 (previously BS6360)
• Insulation: XLPE (Cross-Linked Polyethylene)
• Bedding: PVC (Polyvinyl Chloride)
• Armouring: Single Core: AWA (Aluminium Wire Armour) Multi Core: SWA (Steel Wire Armour)
• Sheath: PVC (Polyvinyl Chloride)
• Sheath Colour: Black
• Voltage Rating: 600/1000V
• Temperature Rating: 0C to +90C
• Minimum Bending Radius: 1.5mm sq - 16mm sq: 6 x overall diameter, 25mm sq and above: 8 x overall diameter

Core Identification:

• 1 Core: Brown
• 2 Cores: Brown, Blue
• 3 Cores: Brown, Black, Grey
• 4 Cores: Blue, Brown, Black, Grey
• 5 Cores: Green/Yellow, Blue, Brown, Black, Grey

Alternative core identification: White Cores with Black numbers
