Sauermann Delta Pack 80 x 60 Elbow Air Con Pump Kit up to 10kw Units
- Easy plug-in electrical connection.
- Low sound level: 22dBA.
- Energy saving.
- Integrated check valve and safety switch.
- 80mm x 60mm Trunking.
ANNUAL SHUTDOWN: We will be closing on Friday 18th December and will re-open on Monday 4th January 2021. During this time you will be able process orders however they will not be dispatched until week commencing 4th January
ANNUAL SHUTDOWN: We will be closing on Friday 18th December and will re-open on Monday 4th January 2021. During this time you will be able process orders however they will not be dispatched until week commencing 4th January
Sauermann Delta Pack 80 x 60 Elbow Air Con Pump Kit up to 10kw Units
Applications:
Description:
NEW
Complete kit intended for wall mounted air conditioning units. Highly resistance to pollution created by the general environment. Quite in operation.
Benefits:
Unmatched reliability Easy plug-in electrical connection Low sound level: 22dBA Energy saving Integrated check valve
Safety switch
Technical Details:
- Max flow rate: 20 l/h
- Max discharge head: 10 m
- Electric power: 14 W
- Electric voltage: 230 V ~ 50/60 Hz
- Alarm contact: NC 8 A resistive - 250 V
- Detection levels in mm: On: 18, Off: 13, Alarm: 21
- Sound level at 3.3ft: 22 dBA
- Protection: IP X4
- Detection: integrated
- Thermal protection (overheating): 90 C (automatic restarting)
- Safety standards: CE
Kit contents :
Si-10 UNIVERS’L piston pump with Integral condensate detector, Clear PVC tube int. 6mm – L: 1 m, foam-insulated over 800 mm, fitted with a “Drain Safe Device” (ACC00216); 1.5 m plug-in power cable: 2 power wires, 2 safety contact wires; 2-part elbow (base and cover); 750 mm duct. ; Ceiling duct (covers hole in the false ceiling); Elbow/Duct gasket; Rubber Elbow/Split gasket; 500 mm flexible hose - int. 15 mm (connects to split); Vent pipe; 6 screws and plugs for fixing duct and elbow; 2 pipe clamps.
| MPN | DP10CE02UN23 |
|---|
