X87-702 - Maxi Blue 230V Drain Sensor Condensate Pump

£137.92 £114.93

X87-702 - Maxi Blue 230V Drain Sensor Condensate Pump

The patented DrainStik® is quick and simple to install or retrofit around any existing installation. The slim line probe, which houses the water sensors and high level alarm can be directly mounted into the drain tube of all types of equipment. With no moving parts to become clogged or stuck it is an ideal alternative to existing float switches.

MaxiBlue uses the same advanced unique technology as the BlueDiamond range. Designed for high humidity environments it benefits from being a small powerful pump that is controlled by our patented sensing technology - only senses when water is present offering an energy efficient drainage solution.

MaxiBlue® pump is slim enough to fit into trunking, powerful enough for distant location and quiet enough for ceiling mounting. It’s your choice.Commisioning is so easy, link pump to sensing option with single wire DIN plug and connect in/out tubing provided - plug and play, fit and forget!

With a higher performance the MaxiBlue® is ideally suited for mid range air conditioning systems. Its exceptional reliability is backed by a multi year warranty and class leading perfomance/suction lift has led it to be installed in environments that are both demanding and expensive to access for maintenance.

The Blue Diamond pump range out performs other condensate pumps and does exactly what you need it to do. We know installers keep us in the van to replace failed or clogged mini pumps and split tubing on peristaltic pumps. BlueDiamond pumps are the reliable alternative so why risk anything else?

Product Features:

  • Proven rotary diaphragm technology as used in BlueDiamond range
  • Flow rate up to 14 l/hr
  • 8 metres Head
  • Dry suction lift up to 8m
  • Self priming
  • Energy Efficient
  • Exceptionally quiet and no vibration
  • Powered by unique water sensors
  • Can be mounted in any orientation

Technical Details:

  • Product Type: Air & Water
  • Pump Type: Rotary Diaphragm
  • Flow: 14.0 l/hr
  • Head: 8.0 m
  • Suction Lift: 8.0 m
  • Silent running less than 21 dbA
  • Voltage Options: 230V 50/60Hz or 110V 50/60Hz
  • Weight (kg): 0.7 Kg
  • Dimensions: 105 x 66 x 56 mm
