DIXL042
Dixell Universal R Refrigeration Controller Thermostat
Designed to replace over 150 models of refrigeration/heating controllers in 32x74mm format
Easy and quick installation
Rapid set-up in 3 simple steps
Dual voltage power supply 12Vac/dc and 230Vac
Specific functions to control twin evaporator defrost
Automatic probe detection
Complete condenser management
Hot Key for quick and easy programming
7 pre-configured applications selectable from parameter
Ex. VAT
£78.63
Inc. VAT
£94.36
Ex. VAT:
Description
Dixell Universal-R Fridge Controller
Universal-R replaces the majority of refrigeration/heating industry standard 32x74 mm format controllers in their most typical applications. It offers a convenient, versatile, easy to install solution, suitable for both a 12Vac/dc and a 230Vac supply.
- Housing self-extinguishing ABS
- Case frontal 32x74mm; depth 70mm
- Mounting panel mounting in a 29x71mm cut-out
- Front protection IP65
- Connections screw terminal block < 2.5 mm2 wiring
- Power supply 12Vac/dc230Vac
- Power absorption 4VA max
- Display 3 digits, red LED, 14,2 mm high
- Data storing on the non-volatile memory (EEPROM)
- Operating temperature 0√∑50C
- Storage temperature -30√∑85C
- Relative humidity 20√∑85% (no condensing)
- Measuring and regulation range NTC probe: -50 to 110C PTC probe: -50 to 150C
- Resolution 0.1C
- Accuracy (at ambient temperature) ±0.5C ±1 digit
¬â€
More Information
| Product Name | Dixell Universal R Refrigeration Controller Thermostat |
|---|---|
| SKU | DIXL042 |
| mpn | DIXL042 |
| Manufacturer | Dixell |
