Aspen Mini Orange Condensate Pump 12L/h 10m Head for HVAC

Aspen Mini Orange Condensate Removal Pump

The Aspen Mini Orange Condensate Removal Pump is the world’s best-selling mini pump, renowned for its unmatched reliability and performance in air conditioning systems. Designed for domestic and small commercial HVAC applications in the UK, this pump ensures efficient condensation removal with a maximum flow rate of 12 L/h and a recommended head of 10m (at 6 L/h flow rate). Its whisper-quiet operation at 21 dB(A) @ 1m makes it ideal for noise-sensitive environments.

Key Features

• High Performance: Delivers a 12 L/h maximum flow rate with a 10m maximum recommended head, ensuring effective condensate removal for units up to 16 kW (54,000 Btu/h).
• Submersible Secondary Reservoir: Includes a reservoir with a float mechanism for reliable water level detection and pump activation.
• Plug & Play Installation: Comes with a plug-and-play cable for quick and hassle-free setup, saving time for HVAC professionals.
• Anti-Siphon Device: Prevents siphoning issues, ensuring consistent pump operation and avoiding airlocks in the system.
• Quiet Operation: Operates at just 21 dB(A) @ 1m, making it perfect for residential and small commercial settings.

Suitability

The Mini Orange is compatible with various air conditioning systems, including high wall split systems, ducted units, floor-standing units, and chassis units. It’s the ideal solution for small units, providing reliable condensate management for both new installations and retrofits.

Installation and Maintenance Tips

For optimal performance, ensure the reservoir is placed flat and horizontal, with the float magnet facing upwards. The pump should not be run dry, and it’s designed for indoor use only. Regular cleaning with an anti-bacterial wash is recommended to prevent sludge buildup, which can affect the float’s movement. If air is noticed in the pipe between the reservoir and pump, install the included anti-siphon device to resolve siphoning issues.

Safety and Usage Guidelines

The Aspen Mini Orange is evaluated for water use only and is unsuitable for swimming pools, marine areas, or oily/dusty environments. It’s non-submersible and requires disconnection from the mains supply before adjustments or servicing. If the power cord is damaged, it must be replaced with the correct assembly from the manufacturer or an authorised service agent.

Why Choose Aspen Mini Orange?

Aspen Pumps is a trusted leader in condensate removal solutions, and the Mini Orange exemplifies their commitment to quality and innovation. Its compact design, ease of installation, and robust performance make it a top choice for HVAC professionals across the UK. Compliant with UK regulations, this pump is perfect for ensuring the efficient and trouble-free operation of your air conditioning systems.

Enhance your HVAC setup with the Aspen Mini Orange Condensate Removal Pump. Order now from AirconSpares.com and benefit from reliable condensate management.
