47484-STR — Capillary hose, L122cm (48") - Straight x Straight

47484-STR 48" Capillary Hose Assembly Straight x Straight with Hex Fittings

Professional 48" capillary hose assembly with hex style fittings. Straight x straight configuration with 1/4" SAE thread. Replaces regular copper capillary tubing and eliminates capillary failure due to work hardening from vibration. Operates to 600 psi (42 bar) and 200°F (93°C). Operational temperature range -20 to 200°F (-29 to 93°C).

Key Features:

• 48" capillary hose assembly
• Hex style fittings with 1/4" SAE thread
• Straight x straight configuration
• Replaces copper capillary tubing
• Eliminates vibration-induced failure
• Max pressure: 600 psi (42 bar)
• Max temperature: 200°F (93°C)
• Operational range: -20 to 200°F (-29 to 93°C)
• Pre-assembled for quick installation

Specifications:

• Length: 48"
• Fittings: Hex style, straight x straight
• Thread: 1/4" SAE
• Max Pressure: 600 psi (42 bar)
• Max Temperature: 200°F (93°C)
• Operational Temperature: -20 to 200°F (-29 to 93°C)
• Application: Replaces copper capillary tubing

Applications:

• Replacing copper capillary tubing
• Pressure switch connections
• Gauge connections
• Oil return circuits
• Vibration-prone installations
• Standard refrigeration repairs

Benefits:

Replaces regular copper capillary tubing and eliminates capillary failure due to work hardening from vibration. Hex style fittings with 1/4" SAE thread provide secure, leak-free connections. Straight x straight configuration for standard installations. 600 psi (42 bar) max pressure handles all common refrigerants. Wide operational temperature range (-20 to 200°F / -29 to 93°C). Extended 48" length ideal for larger refrigeration systems. Essential for professional technicians who need reliable, vibration-resistant capillary connections.

48" capillary hose, hex fittings, straight x straight. Replaces copper tubing. Eliminates vibration failure. 600 psi, 200°F. 1/4" SAE thread. Professional tool.
