Javac JAV-1550 TurboFlow 1/2" ID Vacuum Hose 72" | 1/4" SAE x 3/8" SAE | A2L Rated

Javac JAV-1550 TurboFlow 1/2" ID Vacuum Hose 72" | 1/4" SAE x 3/8" SAE

The highest-flow hose in the Javac EDGE range. The JAV-1550 features an oversized 1/2" internal diameter bore — significantly larger than a standard 1/4" hose — for maximum evacuation speed on HVAC and refrigeration systems. A2L and A3 rated, vacuum rated to 50 microns, and built to handle the rigours of daily trade use.

Key Features

• 1/2" ID Bore — maximum flow for the fastest pull-down times; significantly outperforms standard 1/4" hoses
• A2L & A3 Rated — suitable for R32, R1234yf, R290 and all common refrigerants
• Vacuum Rated to 50 Microns — no permeation or collapse under deep vacuum
• 4-Ply Heavy Duty Construction — 600 PSI working pressure, 3200 PSI burst pressure
• 1/4" SAE x 3/8" SAE Connections — connects directly to vacuum pump (3/8") and manifold or system (1/4")
• Knurled Brass Fittings — easy finger tightening with red Schrader caps
• Part of the Javac EDGE Ultimate Hi-Flow System — pairs with TurboFlow Y-branches and core removal tools for maximum evacuation performance

Technical Specifications

• Part Number: JAV-1550
• EAN: 5060926539652
• Tariff Code: 40094200
• Internal Diameter: 1/2"
• Connections: 1/4" SAE × 3/8" SAE
• Length: 72" (1828.8mm)
• Vacuum Rating: 50 microns
• Hose Construction: 4-ply heavy duty
• Max Working Pressure: 41 bar (600 PSI)
• Burst Pressure: 220 bar (3200 PSI)
• Refrigerant Compatibility: A2L, A3 and all standard refrigerants
• Colour: Black
• Warranty: 12 months
