How Capillary Tubes Work
A capillary tube is a fixed-restriction metering device — a narrow copper tube (typically 0.5–2.2mm internal diameter) that controls refrigerant flow between the high and low pressure sides of the circuit. Unlike a TXV, it has no moving parts and provides no variable control. This makes it reliable and cheap, but sensitive to contamination and only suitable for applications with relatively stable load conditions: domestic fridges, small splits, commercial reach-in coolers.
Common Faults and What They Look Like
Partial Blockage
Symptoms: reduced cooling capacity, elevated suction pressure, prolonged compressor run times, abnormal superheat, ice forming at the capillary outlet. Cause is usually moisture, debris, or oil accumulation at the inlet or within the bore. The system is still running but underperforming.
Complete Blockage
Symptoms: high discharge pressure, near-zero suction pressure, compressor tripping on high-pressure cutout, evaporator completely inactive. Most common cause is a moisture ice plug forming at the pressure reduction point inside the tube. The system effectively stops functioning.
Kinked or Crushed Tube
Physical damage to the capillary changes its internal geometry and creates additional restriction. Check the full length of the tube during visual inspection — bends, kinks, or crush points from previous work are easy to miss.
Diagnostic Approach
Pressure Analysis
Connect manifold gauges and monitor both high and low side simultaneously. A restricted capillary typically shows high head pressure and abnormally low suction pressure. Compare against expected PT values for the refrigerant at current ambient conditions. A digital manifold with Bluetooth is useful here — you can monitor pressure behaviour during startup and stabilisation without standing next to the unit.
Temperature Differential
Measure temperature at the capillary inlet and outlet using a surface probe or infrared thermometer. A functioning capillary shows a clear temperature drop across its length. Abnormal profiles — no drop, or ice forming mid-tube — indicate restriction.
Nitrogen Flow Test
With the system recovered, introduce low-pressure dry nitrogen at the capillary inlet and monitor flow at the outlet. No flow confirms a complete blockage. This avoids refrigerant handling complications and gives a definitive result without contaminating the system.
Capillary Tube Sizing Reference
| Refrigerant | Typical Bore (mm) | Common Length Range (m) |
|---|---|---|
| R134a | 0.6 – 0.8 | 1.5 – 3.0 |
| R410A | 0.5 – 0.7 | 1.2 – 2.5 |
| R600a | 0.7 – 1.0 | 2.0 – 4.0 |
Incorrect sizing on replacement significantly affects system performance. Shorter tubes increase flow (risk of flooding); longer tubes restrict flow (risk of starving the evaporator). Always match OEM specification where possible.
Clearing Blockages
Ice plugs — gentle heat applied to the affected section of the capillary can dissolve a moisture ice plug. If it clears, the system will need a full filter-drier replacement and deep evacuation to remove the moisture source, otherwise it will reblock.
Debris blockages — pressure cycling sometimes dislodges loose contaminants. If not, the tube needs replacing. Attempting to clear a debris blockage by blowing through risks pushing contamination further into the system.
Replacement — recover refrigerant, cut out the old tube, install new tube to OEM spec, replace filter-drier, pressure test with nitrogen, deep evacuate to below 500 microns, recharge by weight.
Preventive Maintenance
- Replace filter-drier on every system opening — it's the capillary tube's primary protection against moisture and debris
- Evacuate to below 500 microns before recharging — moisture is the most common cause of capillary failure
- Record suction and discharge pressures on every service visit to catch developing restrictions early
- Inspect capillary routing for physical damage, especially after any work near the metering device
