Aspen FP3553 High Capacity 11L ERRP Condensate Removal Pump | 230 L/h | 35m Head | Top Inlet

Aspen FP3553 High Capacity 11L ERRP Condensate Removal Pump | Top Inlet

The Aspen FP3553 High Capacity 11L ERRP (Economy Retail Refrigeration Pump) is the top inlet version of the FP3552, designed for multiple refrigeration unit installations in supermarkets and cold stores. Sharing the same ultra-slim 75mm profile, it offers a large 11.1L tank and 230 L/h flow rate — ideal for demanding multi-cabinet installations where a top inlet configuration is required.

With a 35m maximum head, a 2-stage biofilm filter, and a Plug & Play installation, it handles defrost and contaminated water removal efficiently and safely.

Key Features & Benefits

• High capacity 11.1L tank – ideal for multiple refrigeration unit installations
• Top inlet configuration
• Ultra-slim 75mm profile – fits underneath standard retail refrigeration cabinets
• 2-stage filter – catches debris and prevents growth and spread of biofilm
• Low voltage at point of use – safe for retail environments
• Plug & Play – 2m Plug & Play power cable included
• Universal voltage – 100–240V AC 50/60Hz
• IP44 protection
• Thermal protection included
• Flammable refrigerant compatible – designed to minimise spark risk
• 3A NC/NO safety switch
• Modbus RTU compatible – option available (FP3565)

What's in the Box

• Aspen FP3553 High Capacity 11L ERRP pump
• 2m Plug & Play power cable
• 1-1/2" BSP connector (for 40mm ID waste pipe)
• Install manual

Suggested Accessories

• AX5101 – Vinyl tube braided 3/8" (10mm)
• S010371 – Jallystrips
• FP3565 – Modbus RTU option (extra)

Specifications

Also Available

• FP3550 – Compact 4L ERRP, side inlet
• FP3551 – Compact 4L ERRP, top inlet
• FP3552 – High Capacity 11L ERRP, side inlet
• FP3565 – High Capacity 11L ERRP with Modbus RTU
