Javac Edge JAV-1607 Hi-Flow Core Depressor Tool 5/16" x 5/16" | A2L A3 Rated

Javac Edge JAV-1607 Hi-Flow Core Depressor Tool 5/16" x 5/16"

The Javac Edge JAV-1607 is a professional hi-flow core depressor tool with 5/16" flare connections on both ends, designed for use with Schrader valve service ports and 5/16" service hoses. Aircraft grade aluminium body with solid brass connectors and flare faces, deep vacuum rated to 20 microns, and high-pressure rated to 800 psi (55 bar) for safe use on R410A and other high-pressure systems. Compatible with A2L and A3 refrigerants.

Key Features

• 5/16" Flare Connections — for Schrader valve and 5/16" service hose attachment
• Low-Loss Side Port — connect gauges or hoses with negligible discharge for diagnostics and charging
• Aircraft Grade Aluminium — lightweight, strong and corrosion resistant with solid brass connectors and flare faces
• Deep Vacuum Rated (20 Microns) — suitable for full HVAC evacuation workflows
• 800 psi / 55 Bar Rated — safe for high-pressure refrigerants including R410A
• Accurate Core Control — smooth, precise core depression for negligible refrigerant loss and no user frost burn risk
• HNBR Super Seals — high-quality O-rings and back-seat seals compatible with HFC, HFO, A2L and A3 refrigerants
• Durable Finish — wear and corrosion resistant coating for extended field lifespan
• Compact Design — fits easily into tight spaces

Technical Specifications

• Part Number: JAV-1607
• EAN: 5061086311188
• Tariff Code: 84818099
• Connections: 5/16" SAE flare × 2
• Vacuum Rating: 20 microns
• Max Working Pressure: 800 psi / 55 bar
• Body Material: Aircraft grade aluminium
• Seals: HNBR (A1, HFC/HFO, A2L & A3 compatible)
• Warranty: 12 months
