Aspen FP2066/3 Heavy Duty 10 Condensate Tank Pump | 1070 L/h | 4.9m Head
- UK stock – fast dispatch
- UK Mainland Delivery £7.50
- Expert technical support
- Trade accounts available
£270.82
Sale price
£270.82
Regular price
Shipping calculated at checkout.
REFcom Elite registered supplier
Achilles Silver accredited supplier
UK HVAC specialist since 2005
Fast UK dispatch
✓ Trade Pricing | ✓ Technical Support Available | ✓ Secure Checkout
Aspen FP2066/3 Heavy Duty 10 Condensate Removal Tank Pump
The Aspen FP2066/3 Heavy Duty 10 is the high-capacity big brother of the HD6, delivering an impressive 1070 L/h max flow rate for the most demanding commercial and industrial HVAC condensate removal applications. Designed for air handling units (AHUs), dehumidifiers, and large-scale systems handling up to 1460kW (4.9m Btu/h).
With a 4-litre tank, non-return valve, high level safety switch, and easy installation, the HD10 is the go-to solution for large volumes of water removal in tough environments.
Key Features & Benefits
- High flow rate — 1070 L/h max flow
- Non return valve included
- Easy installation
- 4 litre tank capacity
- High level safety switch — 5.0A Normally Closed
- Hard wired with 2m power cable
- IP20 protection
- Continuous rated, Class I appliance
What's in the Box
- Heavy Duty 10 pump
- Hard wired 2m power cable
- Install manual
Suggested Accessories
- FP2007 — Rubber Adaptors 3/4" (19mm) – 1-1/2" (38mm)
- FP2038 — Tube to Soil Stack Adaptor
- AX5101 — Vinyl Tube Braided 3/8" (10mm)
Specifications
| SKU / Part No. | FP2066/3 |
| Max flow | 1070 L/h |
| Max recommended head | 4.9m (at flow rate 1000 L/h) |
| Tank capacity | 4L |
| Sound level | 64dB(A) @ 1m |
| Power supply | 230V AC, 50Hz, 1.1A |
| Rating | Continuous |
| Class | I Appliance |
| Max unit output | Up to 1460kW (4.9m Btu/h) |
| Max ambient temp | 40°C (104°F) |
| Max water temp | 40°C (104°F) |
| Inlet/Outlet | 40mm in, 10mm out |
| IP Protection | IP20 |
| Safety switch | 5.0A Normally Closed |
| Weight | 5.2kg |
| Brand | Aspen Pumps |
| Country of origin | United Kingdom |
Suitability
- Up to 1460kW (4.9m Btu/h) systems
- Dehumidifiers and air handling units (AHUs)
- Large volumes of water removal
- High-demand commercial and industrial HVAC
Also Available
- FP2074/3 — Heavy Duty 6, 900 L/h, 6m head
