Aspen FP3550 Compact 4L ERRP Condensate Removal Pump | Side Inlet
The Aspen FP3550 Compact 4L ERRP (Economy Retail Refrigeration Pump) is designed exclusively to fit underneath retail refrigeration cabinets, allowing efficient removal of defrost and contaminated water. At just 75mm high and with a 530 x 242mm footprint, it slots neatly into the tightest under-cabinet spaces.
With a 35m maximum head and 190 L/h flow rate, a 4.2L tank, and a 2-stage filter to prevent biofilm growth, it's the go-to solution for single and multiple refrigeration unit installations in supermarkets and cold stores.
Key Features & Benefits
- Designed exclusively for retail refrigeration cabinets – ultra-slim 75mm profile fits under standard cabinets
- 2-stage filter – prevents growth and spread of biofilm from contaminated defrost water
- Lightweight & slim – 2.82kg, easy to install and service
- Low voltage at point of use – safe for retail environments
- Plug & Play – 2m Plug & Play power cable included
- Universal voltage – 100–240V AC 50/60Hz
- IP44 protection – suitable for wet environments
- Thermal protection included
- Flammable refrigerant compatible – designed to minimise spark risk
- 3A NC/NO safety switch
- Modbus RTU compatible – option available (FP3565)
- Non-continuous rated, Class II appliance
What's in the Box
- Aspen FP3550 Compact 4L ERRP pump
- 2m Plug & Play power cable
- 1-1/2" BSP connector (for 40mm ID waste pipe)
- Install manual
Suggested Accessories
- AX5101 – Vinyl tube braided 3/8" (10mm)
- S010371 – Jallystrips
- FP3565 – Modbus RTU option (extra)
Specifications
| SKU / Part No. | FP3550 |
| Max flow | 190 L/h @ 0 head |
| Max head | 35m |
| Tank capacity | 4.2L |
| Inlet type | Side inlet (40mm in, 10mm out) |
| Power supply | 100–240V AC, 50/60Hz |
| Rating | Non-continuous, Class II appliance |
| Safety switch | 3A NC/NO |
| IP protection | IP44 |
| Thermal protection | Yes |
| Flammable refrigerant compatible | Yes (minimises spark risk) |
| Max ambient temp | 40°C / 104°F |
| Sound level | 60dB(A) at 1m |
| Weight | 2.82kg |
| Dimensions | 530 x 242 x 75mm |
| Brand | Aspen Pumps (Aspen Pumps Group) |
Also Available
- FP3551 – Compact 4L ERRP with top inlet
- FP3565 – Compact 4L ERRP with Modbus RTU
Ideal Applications
- Retail refrigeration cabinet condensate removal
- Supermarket cold store defrost water removal
- Single and multiple refrigeration unit installations
- Any application requiring an ultra-slim, under-cabinet condensate pump
