Aspen FP2092/3 High-Temp Condensate Pump 900 L/h Max Flow

Aspen FP2092/3 Hot Water Economy Condensate Tank Pump

The Aspen FP2092/3 Hot Water Economy is a high-performance condensate removal tank pump designed for demanding applications where water temperatures reach up to 100°C. With a maximum flow rate of 900 L/h and a maximum head of 6m, it handles high-volume condensate removal from humidifiers, refrigeration systems, and air handling units (AHUs) with ease.

Part of the Aspen Pumps Tank Pump range, the Hot Water Economy is supplied with a hard-wired 2m power cable and an installation manual — ready to install straight from the box.

Key Features & Benefits

• Rated to 100°C – handles the most demanding high-temperature condensate applications
• 900 L/h max flow – suitable for systems up to 1200kW / 4m Btu/h
• 6m max head (flow rate 280 L/h at max head)
• 4L tank capacity – large buffer for high condensate output systems
• 40mm inlet – large bore for high volume applications
• High level safety switch – 5.0A normally closed, for system shutdown on high water level
• Continuous rated – Class I appliance
• Low noise – 64dB(A) at 1m
• IP20 protection
• 12-month warranty – Aspen Pumps quality assurance
• Supplied with hard-wired 2m power cable and install manual

What's in the Box

• Aspen Hot Water Economy pump (FP2092/3)
• Hard-wired 2m power cable
• Install manual

Compatible Accessories

• Aspen FP2038 Self-Sealing Condensate Hose to Soil Pipe Adaptor 6–10mm — Pack of 3 — for routing the 10mm discharge to a soil stack
• DiversiTech RVT-3/8 Reinforced PVC Condensate Drain Hose 10mm — 30m — for the 10mm discharge outlet run
• Hose Jubilee Clip JC00 — 13–20mm, suits 3/8" condensate hose — secure the discharge hose to the outlet

Also Consider

• Aspen FP2074 Heavy Duty 6 Tank Pump — 900 L/h, 6m head — standard temperature alternative at the same flow rate
• Aspen FP2066 Heavy Duty 10 Tank Pump — 1070 L/h, 4.9m head — higher flow rate for larger commercial systems

Specifications

Ideal Applications

• Humidifiers – primary application
• Refrigeration condensate removal
• Air handling units (AHUs)
• Industrial and commercial high-temperature condensate systems up to 1200kW
