The majority of HVAC system failures in the first 12 months of operation can be traced back to commissioning errors rather than equipment defects. Moisture contamination, refrigerant leaks, incorrect charge, and acid formation are almost always preventable — and almost always the result of shortcuts taken during installation and commissioning.
This guide covers the most common HVAC and refrigeration commissioning mistakes, why they happen, and how to avoid them. It is intended as a practical reference for installation engineers, not a beginner's introduction.
Evacuation Mistakes
Using a Manifold Gauge Instead of a Micron Gauge
Manifold gauges operate in the PSI or bar range and read zero at any pressure below approximately 1,000,000 microns. They provide no useful information about vacuum depth during evacuation. An engineer relying on a manifold gauge to verify evacuation has no way of knowing whether the system is at 50,000 microns or 400 microns — the gauge reads the same.
A digital micron gauge connected directly to the system is the only instrument capable of confirming that moisture and non-condensables have been removed to the required level. It is non-negotiable on professional commissioning work.
Connecting the Micron Gauge at the Pump
Even engineers who use a micron gauge often connect it at the pump or manifold rather than at the system. This reads pump performance — not system vacuum depth. The pump may be pulling below 100 microns at its inlet while the system remains at 5,000 microns due to hose restrictions, Schrader cores, or moisture outgassing.
Always connect the micron gauge directly to the refrigeration system. See our guide on how to use a micron gauge properly for the correct placement procedure.
Evacuating Through Schrader Cores
Schrader valve cores create a significant flow restriction during evacuation. Evacuating through cores dramatically increases pull-down time and makes it harder to achieve target micron levels on larger systems. Core removal tools should be used on every evacuation to eliminate this restriction.
Using Undersized or Standard Charging Hoses
Standard 1/4" charging hoses have a small internal diameter that restricts gas flow during evacuation. Dedicated large-bore vacuum hoses significantly reduce pull-down time, particularly on VRF systems and long pipe runs. Using the wrong hoses is one of the easiest performance gains to capture.
Not Replacing Contaminated Vacuum Pump Oil
Contaminated vacuum pump oil is the most common cause of poor evacuation performance. Dark or milky oil has absorbed moisture and contaminants that reduce the pump's ability to achieve a deep vacuum. Oil should be changed after every major evacuation and inspected before every job.
Charging Before a Stable Decay Test
Reaching target micron levels is necessary but not sufficient. The vacuum decay test — isolating the pump and monitoring the micron gauge for 10–15 minutes — confirms the system will hold vacuum without a leak or ongoing moisture source. Charging a system that has not passed a stable decay test is one of the most consequential shortcuts an engineer can take.
See our full guide on how to evacuate an AC system correctly for the complete decay test procedure.
Pressure Testing Mistakes
Skipping Nitrogen Pressure Testing
Pressure testing with dry nitrogen before evacuation is mandatory — not optional. It is the only way to confirm the refrigeration circuit is leak-free before refrigerant is introduced. A system that leaks refrigerant after charging has almost always not been properly pressure tested beforehand.
See our guide on nitrogen pressure testing for HVAC systems for correct procedure and test pressures by refrigerant type.
Using Compressed Air Instead of OFN
Compressed air contains moisture that contaminates the refrigeration circuit. Oxygen in contact with refrigerant oil creates an explosive mixture. Dry nitrogen (OFN — Oxygen Free Nitrogen) from a nitrogen equipment setup is the only safe and compliant option for pressure testing.
Pressurising Directly to Full Test Pressure
Pressurising to full test pressure in a single step risks joint failure and makes early leak identification harder. Always pressurise in stages — typically 10 bar, 20 bar, then full test pressure — pausing at each stage to check for audible leaks.
No Standing Test
A brief pressure check is not a standing pressure test. Small leaks may not be immediately apparent without a sustained hold period. Residential systems require a minimum 1-hour standing test; VRF and commercial systems require 24 hours.
No Documentation
Failing to record pressure test results leaves the installation without an F-Gas compliance record. Test pressure, duration, start and end pressure, ambient temperature, and engineer details must all be documented and retained for the life of the equipment.
Vacuum Pump Mistakes
Using a Single-Stage Pump
Single-stage pumps cannot reliably achieve the sub-500 micron system targets required for professional HVAC commissioning. A two-stage vacuum pump is the correct tool for all refrigeration evacuation work. See our guide on how to choose the correct vacuum pump for sizing guidance.
Using an Undersized Pump for the System Volume
An undersized pump will struggle to achieve target micron levels within a practical timeframe on larger systems. VRF and commercial refrigeration systems require higher-capacity pumps — 12 CFM or above — to pull down efficiently.
Not Changing Oil Between Jobs
Vacuum pump oil absorbs moisture and contaminants during every evacuation. Carrying contaminated oil from one job to the next progressively degrades pump performance. Change oil regularly and always before commissioning critical systems.
System Charging Mistakes
Charging by Weight Without Verifying Pipe Run Correction
Manufacturer refrigerant charge weights are specified for a standard pipe run length. Longer pipe runs require additional refrigerant charge as specified in the installation manual. Failing to apply pipe run correction results in an undercharged system with poor performance and unstable operating pressures.
Charging a Warm System
Refrigerant charge verification by subcooling and superheat requires the system to be operating at stable conditions. Charging a system that has not reached stable operating temperatures produces inaccurate readings and incorrect charge levels.
Not Verifying Charge by Subcooling and Superheat
Charging by weight alone is a starting point, not a verification method. Final charge should always be verified by measuring subcooling on the liquid line and superheat at the suction line under stable operating conditions.
General Commissioning Mistakes
Not Checking Electrical Connections Before Startup
Loose or incorrect electrical connections are a common cause of early component failure. Verify all terminal connections, phase rotation on three-phase systems, and supply voltage before first startup.
No Commissioning Record
A commissioning record documents pressure test results, evacuation micron levels, refrigerant charge weight, operating pressures, subcooling, superheat, and electrical readings. Without it, there is no baseline for future fault diagnosis and no F-Gas compliance documentation.
Rushing the Job
The majority of commissioning mistakes happen under time pressure. Evacuation cannot be rushed — a system that has not reached and held target micron levels is not ready to charge, regardless of how long it has taken. The cost of a callback, compressor replacement, or refrigerant loss far exceeds the time saved by cutting the commissioning process short.
Frequently Asked Questions
What is the most common HVAC commissioning mistake?
Inadequate evacuation — either not achieving target micron levels, not using a micron gauge to verify vacuum depth, or charging before a stable decay test has been completed.
Why do HVAC systems fail shortly after installation?
Early failures are most commonly caused by moisture contamination from inadequate evacuation, refrigerant leaks from poor pressure testing, incorrect refrigerant charge, or acid formation from non-condensables left in the circuit.
Is it necessary to use a micron gauge for every AC installation?
Yes. A micron gauge is the only instrument capable of verifying proper evacuation. It is non-negotiable on professional commissioning work.
Can I skip nitrogen pressure testing on a small split system?
No. Nitrogen pressure testing is required on every installation regardless of system size. It is mandatory for F-Gas compliance documentation.
How do I know if my vacuum pump oil needs changing?
Check the oil colour through the sight glass. Fresh oil is clear or pale yellow. Dark brown or milky oil is contaminated and must be changed before the next evacuation.
